Roller Track 33mm – 44mm Diameter

Our aluminum profile series roller track features a patent pending slide guide design to provide the most compact and efficient use of lateral space. The roller track is a 35mm high by 40 mm wide profile, with a clear anodized finish. The extrusion can be cut with a carbide blade, band saw or cold saw. A captive T-slot runs down the length of each side. With our T-slot nut P/N TSN6, guides, scanners proximity switches, light curtains and other accessories can be easily mounted and positioned on the tracks. The roller track's modular design includes two different diameter wheels, 33mm and 44 mm. The roller track can be assembled and disassembled without tools.

Roller Track — Steel Profile

Steel profile roller track in 4 meter (13.12') lengths with zinc plate finish. Solid steel axle with 33mm diameter x 25mm wide nylon roller center line spacing is 36mm. Use our standard mounting brackets with an adapter bushing.

Slide Guide

The optional slide guide P/N SLG is extruded from a high-density polyethylene for smooth carton glow. It is designed to provide maximum space utilization with the smallest footprint.

Mounting Hardware

Our mounting brackets, QS, QF, and QDS, mount the roller track to the rack frame.

Power Track

New Power Drive System Usages

Operation: The power drive unit is designed to operate between two of Quixxsmart's roller channel. The power slide belt will be in contact with the bottom of the product or package that is being moved. The edges of the package/ product would ride on the 2 non-powered sections of roller track.

Overview: The power drive system consists of a modular conveyor contained in a Quixxsmart Structures 35 x 40 mm aluminum roller channel. Power is transmitted by a circular .250" cross section urethane belt riding in a semicircular groove on the circumference of the nylon rollers ride on polished stainless steel axles. This belt is industry proven and is field weldable.

Mounting to the conveyor legs or frame is achieved with "U" shaped mounting saddles.

Roller Track Splice: The length of the power drive system can be easily modified using QSPL splices to extend the track. Lengths of the roller channel can be cut with a carbide blade miter saw.

Usages: This system can be used for the handling of containers, for the transfer of fixtures in custom manufacturing or assembly cells or for pick cells where the power drive belt would be mounted to flow racks and move containers through order fulfillment. Please call with your specific requirements.

Electrical: Motive power is a variable speed drive fractional horse power DC gear motor driving a power drive pulley.

This brushless motor features silent operation, high torque and compact size (3" dia. and 4.5" long). The power drive motor requires a 20A 120V circuit and can be plugged into an outlet. The variable speed drive is included with the motor drive unit.
